Pole Length – Above Ground: 14 ft.
Embed Section – 3.4 ft.
Material: The pole shaft is a seamless 6063-T6 aluminum alloy extrusion having a uniform wall thickness of 0.250″, 0.188″, 0.156″ or 0.125″. Along with CCTV equipment, the sides of the shaft may be drilled for mounting light fixtures. All aluminum alloys shall comply with metallurgical and mechanical properties set forth in the Aluminum Association Standards.
Finishes: All exterior metal surfaces are mechanically cleaned to remove all oxides and contaminants prior to coating. The standard finish is a polyester thermosetting powder coating applied to the surface of the substrate to a minimum of 3 mils for all color finishes.
01- Satin Aluminum – Please note this selection is powder-coated to match an aluminum look.
BA- Black Powder Coat
BH- White Powder Coat
BM- Dark Bronze Powder Coat
GC- Gray Powder Coat
Dimensions:
Height: 14′ Above Ground
Embed Section: 3.4′
Wall Thickness: 0.125″
Butt Diameter: 4″
Top Diameter: 4″
