Shaft: Square tapered; 7.32″ x 39′
Pole Base Diameter: 7.32″
Height: 39 ft.
Hand Hole Dimensions: 4″ x 6.5″
Bolt Circle: 13.5″
Anchor Bolt: 1″ x 36″ x 4″
Shipping Weight: 801 lbs.
Color: Bronze powder coating is standard but you can select from other finishes that are available.
Made in USA.
The pole shaft is two section design, each section being fabricated from standard 7 gauge (0.1793″) steel. The pole shaft material is a weldable grade hot rolled commercial quality carbon steel with a guaranteed minimum yield strength of 55,000 psi after fabrication. Each section is one-piece construction with a full length longitudinal weld and is square in cross-section having a uniform taper of 0.10 inches of diameter change per foot of length.
Anchor bolts are fabricated from commercial quality hot rolled carbon steel bar that meets or exceeds a minimum yield strength of 55,000 psi. Four properly sized anchor bolts, each with two regular hex nuts and washers, are furnished and shipped with all poles unless otherwise specified. Anchor bolts shall have the threaded end galvanized a minimum of 8 inches in accordance with ASTM A-153. Fully galvanized anchor bolts are available upon request.
The anchor base is fabricated from structural quality hot rolled carbon steel plate that meets or exceeds a minimum yield strength of 36,000 psi. The anchor base telescopes the pole shaft and is circumferentially welded top and bottom. All welds are performed in accordance with the American Welding Society specification AWS D1.1, latest edition.
An oval reinforced gasketed handhole, having a nominal 4″ x 6-1/2″ inside opening, located 1′-6″ above the base, is standard on all poles. A grounding provision is located inside the handhole ring.
All exterior metal surfaces are mechanically cleaned to remove all oxides and contaminants prior to coating. The standard finish is a polyester thermo-setting powder coating applied to the surface of the substrate to a minimum of 3 mils for all color finishes. Galvanizing is available upon request. Standard color is dark bronze.
