39 ft. Round Tapered Steel Pole | CPRTS390790

Higher EPA. More Equipment. More Confidence.

Built with thicker diameters and vibration control for CCTV performance.

Vibration damper included for steadier video and PTZ clarity

Made in the USA for consistent quality and support

Thicker taper = higher EPA capacity (thicker butt + top OD)

The CPRTS390790 is a 39 ft round tapered steel camera pole with a 4-bolt base, designed for secure mounting of CCTV and site equipment.

The pole shaft is manufactured from weldable-grade carbon steel tubing conforming to ASTM A595 Grade A.
All welds conform to AWS D1.1 using ER70S-6 electrodes.
A reinforced handhole with grounding provision supports clean, serviceable field wiring.

Key Dimensions
Height: 39 ft
Gauge: 07 ga
Butt diameter: 9.0 in
Top diameter: 3.5 in
Bolt circle: 13–14 in
Base plate: 12.75 in square (4-bolt pattern)
Anchor bolts: 1.25"x48"x6"

Maximum equipment weight: 425 lb

EPA (Effective Projected Area) – sq ft
90 mph: 36.6
100 mph: 28.8
110 mph: 26.7
120 mph: 21.9
130 mph: 18.2
140 mph: 15.4

EPA values are calculated in accordance with 2009 AASHTO LTS-5 (25-year design life) using the maximum equipment weight shown. If equipment weight is exceeded or a different design life/code is required, consult the factory.
